HJS Universal Parts - Installation technique
We have everything you need for trouble-free installation: heat shields, general-purpose brackets, springs, pipe clamps as well as rubber parts and mounting components.
hjs-no. | description | thickness | width | length |
|---|---|---|---|---|
| 90 60 3152 | Heat shield | 2.5 mm | 30 mm | 330 x 660 mm |
| 90 60 3151 | Heat shield | 2.5 mm | 30 mm | 330 x 500 mm |
| 90 60 3150 | Heat shield | 2.5 mm | 30 mm | 330 x 330 mm |
hjs-no. | description | thickness | width x length |
|---|---|---|---|
| 83 00 0027 | Material: 1.4828; formable | 0,1 mm / 5mm | 1000 x 1000 mm |
| 83 00 0025 | Material: 1.4828; formable | 0,1 mm / 5mm | 500 x 500 mm |
| 83 00 0020 | Material: 1.4828; formable | 0,1 mm / 5mm | 250 x 500 mm |
hjs-no. | description | thickness | width x length |
|---|---|---|---|
| 83 00 0040 | Material: 1.4828; formable | 0,1 mm | 1000 x 1000 mm |
| 83 00 0035 | Material: 1.4828; formable | 0,1 mm | 500 x 500 mm |
| 83 00 0030 | Material: 1.4828; formable | 0,1 mm | 500 x 1000 mm |
| 83 00 0015 | Material: 1.4828; formable | 0,1 mm | 250 x 500 mm |
hjs-no. | description |
|---|---|
| 90 60 0121 | Stainless steel cable tie / 5 x 350 mm |
| 90 60 0130 | 50 x 2,0 mm / black / heat resistance up to 1.000° C |
| 90 60 0110 | 50 x 1,5 mm / heat resistance up to 800° C |
hjs-no. | description |
|---|---|
| 90 60 0132 | 127 x 1000 mm |
| 90 60 0133 | 191 x 1000 mm |
| 90 60 0134 | 252 x 1000 mm |
| 90 60 0131 | 78 x 2200 mm |
hjs-no. | description | thickness | width x length |
|---|---|---|---|
| 83 00 0043 | Insulation, loose | 5 mm | 500 x 250 mm |
| 83 00 0047 | Insulation, loose | 5 mm | 1000 x 1000 mm |
| 83 00 0045 | Insulation, loose | 5 mm | 500 x 500 mm |
hjs-no. | description | screw thread |
|---|---|---|
| 90 60 4553 | NOx - Sensor Threaded Ring | M 20 x 1,5 - 6H |
| 90 60 7690 | λ - Sensor Threaded Ring, Straight | M 18 x 1,5 |
| 90 60 9725 | λ - Sensor Threaded Ring, 45° Angle | M 18 x 1,5 |
| 83 00 0001 | NOx - Sensor Screwed Sealing Pluge | M 20 x 1,5 - 6H |
| 93 02 4806 | Temperatur PT - Threaded Ring | M 14 x 1,5 |
| 83 00 0244 | λ - Sensor Screwed Sealing Plug | M 18 x 1,5 |
| 90 60 9724 | λ - Sensor Threaded Ring with Bevel | M 18 x 1,5 |
| 90 60 0023 | Screwed Sealing Plug | M 14 x 1,5 |
| 90 60 0619 | CO-Sensor Threaded Ring | M 14 x 1,5 |
hjs-no. | description | diameter | length |
|---|---|---|---|
| 90 60 0027 | Sraight Holder, Stainless Steel | 10 mm | 250 mm |
| 90 60 0026 | Straight Holder, Stainless Steel | 10 mm | 220 mm |
hjs-no. | description | Diameter x Length |
|---|---|---|
| 90 60 0512 | Stainless Steel Spring | 8 x 80 mm |
| 90 60 0515 | Bracket | Stainless Steel |
hjs-no. | diameter inside |
|---|---|
| 90 60 5599 | 73 mm |
| 90 60 7097 | 79 mm |
| 90 60 5091 | 45 mm |
| 90 60 5297 | 58 mm |
| 90 60 5398 | 63 mm |
| 90 60 5597 | 70 mm |
| 90 60 5198 | 54 mm |
| 90 60 5199 | 51.5 mm |
hjs-no. | picture | drawing | description | rubber thickness |
|---|---|---|---|---|
| 90 60 7112 |  |  | Rubber Pad HD | 38 mm |
| 90 60 1900 | |  | Rubber Pad | 34 mm |
| 90 60 1960 |  |  | Rubber-Metal Element | 34 mm |
